IB Physics Unit 5 Electricity and magnetism: Electric fields Notes

8 | Electricity

IB Physics Content Guide

Big Ideas

  •       Electricity consists of charged particles moving in a continuous circuit
  •       Voltage, Current, and Resistance are related to each other though Ohm’s
    Law
  •       The total current flowing into a junction must equal the total current
    flowing out of that same junction
  •       The voltage dropped around a continuous loop traced in a circuit must
    equal the voltage provided
  •       Resistors can be combined in different ways to produce different results
  •       It is possible that the act of taking a measurement will change the
    value being measured
  •       The resistance of a wire is affected by its thickness, length, and
    material resistivity
  •       Many applications use a potential divider circuit design to produce a
    result when certain conditions are met
  •       The voltage that a battery can supply is related to its internal
    resistance

Content Objectives



8.1 – Electrical Current

  • I can quantify charge in terms of Coulombs
  • I can calculate the charge of a certain # of electrons and the # of electrons for a given charge
  • I can describe current in terms of amps and coulombs per second
  • I can describe the subatomic properties of a conductor to allow charge to flow
  • I can the electron drift speed for a given current and wire
  • I can use Kirchhoff’s First Law to analyze the current flowing in an out of a junction

8.2 – Ohm’s Law and Resistance

  • I can use Kirchhoff’s Second Law to analyze the current flowing in an out of a junction
  • I can qualitatively describe voltage, current, and resistance
  • I can mathematically relate voltage, current, and resistance using Ohm’s Law
  • I can describe the difference between ohmic and non-ohmic resistors
  • I can identify groups of resistors as being connected in series of parallel
  • I can calculate the equivalent resistance for resistors connected in series
  • I can calculate the equivalent resistance for resistors connected in parallel
  • I can quantitatively describe how adding resistors changes the equivalent resistance

8.3 – Circuits

  • I can calculate the equivalent resistance for resistors in a combination circuit with series AND parallel
  • I can describe how voltage is divided across resistors in series
  • I can describe how current is divided across parallel branches in a circuit
  • I can use a circuit diagram to calculate V, I, and R for resistors in simple series or parallel circuits
  • I can use a circuit diagram to calculate V, I, and R for resistors in a combination circuit

8.4 – Measuring Circuits and Resistivity

  • I can explain how a voltmeter or ammeter must be connected in a circuit
  • I can identify the resistance required for an ideal voltmeter or ammeter
  • I can predict the reading on a meter when given its internal resistance
  • I can calculate a meter’s internal resistance from a meter reading and circuit diagram
  • I can calculate the electrical power of a component when given voltage, current, or resistance
  • I can qualitatively describe the factors that affect a wire’s resistance
  • I can define the resistivity of a meter with proper units
  • I can calculate for an unknown variable in the resistivity formula

8.5 – Voltage Dividers and Batteries

  • I can identify the different circuit diagram symbols for different types of resistors
  • I can describe how environmental changes can affect the resistance of LDRs and Thermistors
  • I can describe how changing resistor values can affect the voltage drop experienced
  • I can design a potential divider circuit to perform a certain task
  • I can compare the differences between primary and secondary cells
  • I can describe the mechanics required to recharge a battery
  • I can define the electromotive force and describe how is it is different than the battery’s voltage
  • I can solve for a circuit that includes a battery with internal resistance
  • I can describe how a battery’s voltage changes over time

8 | Electricity

Shelving Guide

Charge



Current

Symbol

q

Unit

Coulombs [C]

Symbol

I

Unit

Amperes [A]

Charge Of 1 Electron

1.6 × 10-19 C

Unit in
terms of Coulombs

# of Electrons per Coulomb

6.25 × 1018 e

Drift Speed



Variable
Symbol

Unit



Data
Booklet Equation:

Current

I

A



# of
Electrons per m3

n



Cross
Sectional Area

A

M2





Drift
Speed

v

m s-1



Cross Sectional Area:

Charge

q

C



Electrical Properties

Property

What is
it?

Symbol

Unit

Voltage

Potential Difference

V

Volts [V]

Current

The rate at which charges move through a wire

I

Amperes [A]

Resistance

How hard it is for a current to

flow through a conductor

R

Ohms [Ω]

Kirchhoff’s Laws

The total current coming into a junction must equal the
total current leaving the same junction

The sum of the voltages (potential differences)
provided must equal the voltages dissipated across components

Across
resistors

Always Negative

Entering
Junction

à

Positive

Negative
to Positive

à

Positive

Exiting
Junction

à

Negative

Positive
to Negative

à

Negative

Ohm’s Law

Ohmic
Resistor

Non-Ohmic
Resistor

Equivalent Resistance



Drawing
with R1 and R2

Equation

Series

Parallel

Measuring Circuits



Ammeter

Voltmeter

Ideal
Resistance

R = 0 Ω

R = Ω

How is
it connected to the component being measured?

Ammeters must be connected in series

Voltmeters must be connected in parallel

Drawing
of meter measuring R1

Resistivity



Variable
Symbol

Unit



Data
Booklet Equation:

Resistivity

ρ

Ω m



Resistance

R

Ω



Cross
Sectional Area

A

m2



Cross Sectional Area:

Length

L

m



Power

In terms
of V and I

In terms
of I and R

In terms
of V and R

Voltage Dividers



Light-Dependent
Resistor

Thermistor

Symbol

Relationship

Light

Increases

Heat

Increases

Resistance

Decreases

Resistance

Decreases

Circuit

Switch turns on in the dark:

Switch turns on in a fire:

Batteries

Primary
Cells

Secondary
Cells

Cannot be recharged

Can be recharged by passing a current through the battery in
the opposite direction as it would normally travel



Variable
Symbol

Unit



Data
Booklet Equation:

Electromotive
Force (e.m.f)

ε

V



Current

I

A



Circuit
Resistance

R

Ω





Internal
Resistance

r

Ω







Electric charge (q or Q)

  • Property of matter, either positive, + (e.g. protons), negative, – (e.g. electrons) or neutral (e.g. neutrons).
  • Opposite charges attract each other, while like charges repel each other.
  • Units: Coulombs (C).
    • Definition: “1 C is the charge transported by a current of one ampere in one second”.
  • Elementary/electron charge (e): The basic unit, equal to 1.6 x 10^-19 C.
  • Principle of conservation of charge: Total charge is always conserved.

Materials

  • Conductors: have many free electrons that act as charge carriers, such as metals.
  • Insulators: do not have many free electrons and reduce the current, such as rubber.

Electric force

Coulomb’s law: Electric force = KQ1Q2/r^2, where Q1 and Q2 are the bodies’ charges, r is the distance between them and k is Coulomb’s constant, which is equal to 1/(4πεo); εo is the permittivity of free space (vacuum). Electric fields
  • Electric field: space that surrounds a charge and influences small test charges, which do not disturb the field. No electric field inside a conducting sphere.​
  • Electrical field strength: “The electrical field strength is defined as the electric force per unit charge experience by a small positive point/test charge at a given point.”
    • E = F/q = KQ/r^2, where q is the charge experiencing the field and Q the charge creating the field.
    • Units: NC^-1 or Vm^-1.
  • Field’s lines: show the direction of the force on a small positive test charge, which is the same direction as the electrical field strength (E).​ Always away from + and into -.
    • The field is stronger where the lines are more packed together.
    • The field lines never touch each other.

Electric current (I)​

  • Electric current: rate of flow of electrical charge, carried by charge-carriers, such as electrons (e-), also called conduction electrons.
  • Direction: Electrons travel in the opposite direction to the field, as they have negative charge.
  • Occurrence: It occurs in a conductor only with the presence of an electric field.
    • Normally, there is movement of charges in both directions, so it is cancelled and no current flows.
    • When the electric field “rises”, the current forms itself instantaneously.​
  • Direct current: when there is motion of charges in the same (and only one) direction.​
  • Positive ions remain static in this process, receiving kinetic energy from the electrons.
  • Formula: I = total charge that moved past a point/time taken for this movement = ∆q/∆t.
  • Units: Amperes (A). 1 A = 1 C s^-1.
Tip: “We have to distinguish the conventional current – the flow of positive charge – and the flow of charge-carriers. If protons carry positive charge from A to B, then we have no problem in saying that the current flows from A to B. A gets less positive, B gets more positive. But, if electrons carry negative charge from A to B, clearly the current is in the opposite direction. A is now getting more positive and B less positive. So we have to say that the conventional current is moving from B to A.” (Kognity, 2016)

Electric potential (V)

  • Definition: “The electric potential of a point is the work per unit charge required to move a small positive test charge”. V = W/q.
  • Units: Volts (V), 1 V = 1 JC^-1.
  • Equipotential lines: Lines in which the potential is equal.
    • Perpendicular to the electric field lines.​8.jpg
    • Potential gradient: the distance between equipotential lines is equal to: – electrical field strength = – E = -V/d.
  • Electric potential difference (pd/∆V): “The electric potential difference between two points is the work done per unit charge to move a small point charge from one point to the other.” It is sometimes called voltage.
    • Path: The actual path of a charge does not affect the amount of work done.
    • Energy: If a charge move because of the field, it will increase its kinetic energy and decrease its potential energy.
  • Electronvolt (eV): ​”Work done to move one electron across a potential difference of one volt.” 1 eV = 1.6 x 10^-19 J.

ELECTRIC CHARGES AND FIELDS

ELECTRIC CHARGE

Charge is something associated with matter due to which it produces and experiences electric and magnetic effects.
There are two types of charges :
  • Positive charge
  • Negative charge



Positive and negative charges : Positive charge means the deficiency of electrons while negative charge means excess of electrons. In any neutral body the net charge is equal to zero
i.e., the sum of positive charges is equal to the sum of negative charges.

Charge is a scalar quantity and its SI unit is coulomb (C).

CONDUCTORS AND INSULATORS

The materials which allow electric charge (or electricity) to flow freely through them are called conductors. Metals are very good conductors of electricity. Silver, copper and aluminium are some of the best conductors of electricity. Our skin is also a conductor of electricity. Graphite is the only non-metal which is a conductor of electricity.
All metals, alloys and graphite have ‘free electrons’, which can move freely throughout the conductor. These free electrons make metals, alloys and graphite good conductor of electricity.
Aqueous solutions of electrolytes are also conductors.



The materials which do not allow electric charge to flow through them are called non-conductors or insulators.
For example, most plastics, rubber, non-metals (except graphite), dry wood, wax, mica, porcelain, dry air etc., are insulators.
Insulators can be charged but do not conduct electric charge. Insulators do not have ‘free electrons’ that is why insulators do not conduct electricity.
Induced charge can be lesser or equal to inducing charge (but never greater) and its max. value is given by
Q’ = – Q (1 – 1/k), where ‘Q’ is inducing charge and ‘K’ is the dielectric const. of the material of the uncharged body.
For metals k = ∞ ⇒ Q’ = – Q.

METHODS OF CHARGING

  1. By friction : By rubbing two suitable bodies, given in box one is charged by +ve and another by –ve charge in equal amount.
+ve : Glass rod, Fur, Dry hair, Wool
-ve : Silk, Ebonite rod, Comb, Amber



Note:- Electric charges remain confined only to the rubbed portion of a non-conductor but in case of a conductor, they spread up throughout the conductor.
  1. By conduction : Charging a neutral body by touching it with a charged body is called charging by conduction.
It is important to note that when the bodies are charged by conduction, a charged and an uncharged bodies are brought into contact and then separated, the two bodies may or may not have equal charges.
If the two bodies are identical the charges on the two will be equal.
If the two bodies are not identical, the charges will be different.
The potential of the two bodies will always be the same.
  1. By induction : Charging a body without bringing it in contact with a charged body is called charging by induction.
First rearrangement of charge takes place in metal rod B. When the rod B is connected to earth, electrons flow from earth to the rod B thus making it -vely charged
The magnitude of elementary positive or negative charge (electron) is same and is equal to 1.6 × 10–19 C.

PROPERTIES OF ELECTRIC CHARGE

  • Similar charges repel and dissimilar charges attract each other.
In rare situation you may find similar charged bodies attracting each other. Suppose a big positive charged body is placed near a small positively charged body then because of induction, opposite charge produced on the small body makes it to attract the other body.
  • A charged body attracts light uncharged bodies, due to polarisation of uncharged body.
Fig : When a positively charged balloon is placed in contact with the wall, an opposite charge is induced with the wall, the balloon stick to the wall due to electrostatic attraction
  • Charge is conserved i.e., the charge can neither be created nor be destroyed but it may simply be transferred from one body to the other.
Thus we may say that the total charge in the universe is constant or we may say that charges can be created or destroyed in equal and opposite pair. For example
(Pair-production process)
Positron is an antiparticle of electron. It has same mass as that of electron but equal negative charge.
(Pair-annihilation process)
  • Charge is unaffected by motion
    This is also called charge invariance with motion
Mathematically, (q)at rest = (q)in motion
  • Quantisation of charge – A charge is an aggregate of small unit of charges, each unit being known as fundamental or elementary charge which is equal to e = 1.6 × 10–19 C. This principle states that charge on any body exists as integral multiple of electronic charge. i.e. q = ne where n is an integer.
According to the concept of quantisation of charges, the charge q cannot go below e. On macroscopic scale, this is as good as taking limit q0 → 0.



Quantisation of electric charge is a basic (unexplained) law of nature. It is important to note that there is no analogous law of quantisation of mass.
Recent studies on high energy physics have indicated the presence of graphs with charge 2e/3, e/3. But since these cannot be isolated and are present in groups with total charge, therefore the concept of elementary charge is still valid.

COULOMB’S LAW

The force of attraction or repulsion between two point charges (q1 and q2) at finite separation (r) is directly proportional to the product of charges and inversely proportional to the square of distance between the charges and is directed along the line joining the two charges.
i.e., or
where ε is the permittivity of medium between the charges.
If ε0 is the permittivity of free space, then relative permittivity of medium or dielectric constant (K), is given by

The permittivity of free space

and = 9 × 109 Nm2 C–2.
Also in CGS system of unit.
Coulomb’s law may also be expressed as

Let F0 be the force between two charges placed in vacuum then

Hence
Therefore we can conclude that the force between two
charges becomes 1/K times when placed in a medium of
dielectric constant K.



The value of K for different media

DIELECTRIC

A dielectric is an insulator. It is of two types –
  • Polar dielectric
  • Non-polar dielectric



SIGNIFICANCE OF PERMITTIVITY CONSTANT OR DIELECTRIC CONSTANT
Permittivity constant is a measure of the inverse degree of permission of the medium for the charges to interact.



DIELECTRIC STRENGTH
The maximum value of electric field that can be applied to the dielectric without its electric breakdown is called its dielectric strength.

DIFFERENCE BETWEEN ELECTROSTATIC FORCE AND GRAVITATIONAL FORCE

Note:- Both electric and gravitational forces follow inverse square law.

VECTOR FORM OF COULOMB’S LAW

SUPERPOSITION PRINCIPLE FOR DISCRETE CHARGE DISTRIBUTION: FORCE BETWEEN MULTIPLE CHARGES

The electric force on q1 due to a number of charges placed in air or vacuum is given by
Note:- Coulomb’s law is valid if m and if charges are point charges.

FORCE FOR CONTINUOUS CHARGE DISTRIBUTION

A small element having charge dq is considered on the body. The force on the charge q1 is calculated as follows
Now the total force is calculated by integrating under proper limits.
i.e.,
where is a variable unit vector which points from each dq, towards the location of charge q1 (where dq is a small charge element)

TYPES OF CHARGE DISTRIBUTION

  • Volume charge distribution : If a charge, Q is uniformly distributed through a volume V, the charge per unit volume ρ (volume charge density) is defined by
; ρ has unit coulomb/m3.
  • Surface charge distribution : If a charge Q is uniformly distributed on a surface of area A, the surface charge density , is defined by the following equation
σ has unit coulomb / m2
  • Linear charge distribution : If a charge q is uniformly distributed along a line of length λ, the linear charge density λ, is defined by
, λ has unit coulomb/m.



If the charge is non uniformly distributed over a volume, surface, or line we would have to express the charge densities as
where dQ is the amount of charge in a small volume, surface or length element.



In general, when there is a distribution of direct and continuous charge bodies, we should follow the following steps to find force on a charge q due to all the charges :
  • Fix the origin of the coordinate system on charge q.
  • Draw the forces on q due to the surrounding charges considering one charge at a time.
  • Resolve the force in x and y-axis respectively and find and
  • The resultant force is and the direction is given byand the direction is given by

CALCULATION OF ELECTRIC FORCE IN SOME SITUATIONS

  • Force on one charge due to two other charges
Resultant force on q due to q1 and q2 are obtained by vector addition of individual forces
The direction of F is given by
  • Force due to linear charge distribution
Let AB is a long (length ) thin rod with uniform distribution of total charge Q.
We calculate force of these charges i.e. Q on q which is situated at a distance a from the edge of rod AB.
Let, dQ is a small charge element in rod AB at a distance x from q .
The force on q due to this element will be
where μ is linear charge density i.e., μ = Q / .
so, newton



KEEP IN MEMORY
  1. When the distance between the two charges placed in vacuum or a medium is increased K-times then the force between them decreases K2-times. i.e., if F0 and F be the initial and final forces between them, then
  2. When the distance between the two charges placed in vacuum or a medium is decreased K-times then the force between them increases K2-times. i.e., if Fo and F be the initial and final forces then F = K2Fo
  3. When a medium of dielectric constant K is placed between the two charges then the force between them decreases by K-times. i.e., if Fo and F be the forces in vacuum and the medium respectively, then
  4. When a medium of dielectric constant K between the charges is replaced by another medium of dielectric constant K’ then the force decreases or increases by (K/K’) times according as K’ is greater than K or K’ is less than K.

ELECTRIC FIELD

The space around an electric charge, where it exerts a force on another charge is an electric field.
Electric force, like the gravitational force acts between the bodies that are not in contact with each other. To understand these forces, we involve the concept of force field. When a mass is present somewhere, the properties of space in vicinity can be considered to be so altered in such a way that another mass brought to this region will experience a force there. The space where alteration is caused by a mass is called its Gravitational field and any other mass is thought of as interacting with the field and not directly with the mass responsible for it.



Similarly an electric charge produces an electric field around it so that it interacts with any other charges present there. One reason it is preferable not to think of two charges as exerting forces upon each other directly is that if one of them is changed in magnitude or position, the consequent change in the forces each experiences does not occur immediately but takes a definite time to be established. This delay cannot be understood on the basis of coulomb law but can be explained by assuming (using field concept) that changes in field travel with a finite speed. (≈ 3 × 108 m / sec).



Electric field can be represented by field lines or line of force.
The direction of the field at any point is taken as the direction of the force on a positive charge at the point.



Electric field intensity due to a charge q at any position () from that charge is defined as
where is the force experienced by a small positive test charge q0 due to charge q.
Its SI unit is NC–1. It is a vector quantity.
If there are more charges responsible for the field, then
where are the electric field intensities due to charges q1, q2, q3…..respectively.

ELECTRIC LINES OF FORCE

These are the imaginary lines of force and the tangent at any point on the lines of force gives the direction of the electric field at that point.



PROPERTIES OF ELECTRIC LINES OF FORCE
  1. The lines of force diverge out from a positive charge and converge at a negative charge. i.e. the lines of force are always directed from higher to lower potential.

  1. The electric lines of force contract length wise indicating unlike charges attract each other and expand laterally indicating like charges repel each other.
  1. The number of lines that originate from or terminate on a charge is proportional to the magnitude of charge.
i.e.,
  1. Two electric lines of force never intersect each other.
  2. They begin from positive charge and end on negative charge i.e., they do not make closed loop (while magnetic field lines form closed loop).
  1. Where the electric lines of force are
    1. close together, the field is strong (see fig.1)
    2. far apart, the field is weak (see fig.2)
  1. Electric lines of force generate or terminate at charges /surfaces at right angles.

ELECTRIC FIELD FOR CONTINUOUS CHARGE DISTRIBUTION

If the charge distribution is continuous, then the electric field strength at any point may be calculated by dividing the charge into infinitesimal elements. If dq is the small element of charge within the charge distribution, then the electric field at point P at a distance r from charge element dq is
Non conducting sphere (dq is small charge element)
dq = λdl (line charge density)
= σ ds (surface charge density)
= ρdv (volume charge density)
The net field strength due to entire charge distribution is given by
where the integration extends over the entire charge distribution.



Note:- Electric field intensity due to a point charge q, at a distance (r1 + r2) where r1 is the thickness of medium of dielectric constant K1 and r2 is the thickness of medium of dielectric constant K2 as shown in fig. is given by

CALCULATION OF ELECTRIC FIELD INTENSITY FOR A DISTRIBUTION OF DIRECT AND CONTINUOUS CHARGE

  1. Fix origin of the coordinate system where electric field intensity is to be found.
  2. Draw the direction of electric field intensity due to the surrounding charges considering one charge at a time.
  3. Resolve the electric field intensity in x and y-axis respectively and find ΣEx and ΣEy
  4. The resultant intensity is and where θ is the angle between and x-axis.
  5. To find the force acting on the charge placed at the origin, the formula F = qE is used.



ENERGY DENSITY
Energy in unit volume of electric field is called energy density and is given by
,
where E = electric field and εo= permittivity of vacuum

ELECTRIC FIELD DUE TO VARIOUS CHARGE DISTRIBUTION

  • Electric Field due to an isolated point charge
  • A circular ring of radius R with uniformly distributed charge
When x >> R,
[The charge on ring behaves as point charge]
E is max when . Also Emax
  • A circular disc of radius R with uniformly distributed charge with surface charge density σ
  • An infinite sheet of uniformly distributed charges with surface charge density σ
  • A finite length of charge with linear charge density
and
Special case :
For Infinite length of charge,
  and
  • Due to a spherical shell of uniformly distributed charges with surface charge density σ
Ein = 0 (x < R)
  • Due to a solid non conducting sphere of uniformly distributed charges with charge density ρ




  • Due to a solid non-conducting cylinder with linear charge density λ
Eaxis = 0, ,
,
In above cases,



KEEP IN MEMORY
  1. If the electric lines of force are parallel and equally spaced, the field is uniform.
  2. If E0 and E be the electric field intensity at a point due to a point charge or a charge distribution in vacuum and in a medium of dielectric constant K then
E = KE0
  1. If E and E’ be the electric field intensity at a point in the two media having dielectric constant K and K’ then
  1. The electric field intensity at a point due to a ring with uniform charge distribution doesn’t depend upon the radius of the ring if the distance between the point and the centre of the ring is much greater than the radius of the ring. The ring simply behaves as a point charge.
  2. The electric field intensity inside a hollow sphere is zero but has a finite value at the surface and outside it (; x being the distance of the point from the centre of the sphere).
  3. The electric field intensity at a point outside a hollow sphere (or spherical shell) does not depend upon the radius of the sphere. It just behaves as a point charge.
  4. The electric field intensity at the centre of a non-conducting solid sphere with uniform charge distribution is zero. At other points inside it, the electric field varies directly with the distance from the centre (i.e. E ∝ x; x being the distance of the point from the centre). On the surface, it is constant but varies inversely with the square of the distance from the centre (i.e.). Note that the field doesn’t depend on the radius of the sphere for a point outside it. It simply behaves as a point charge.
  5. The electric field intensity at a point on the axis of non-conducting solid cylinder is zero. It varies directly with the distance from the axis inside it (i.e. E ∝ x). On the surface, it is constant and varies inversely with the distance from the axis for a point outside it (i.e. ).

MOTION OF A CHARGED PARTICLE IN AN ELECTRIC FIELD

Let a charged particle of mass m and charge q be placed in a uniform electric field, then electric force on the charge particle is
∴ acceleration, (constant)
  • The velocity of the charged particle at time t is,
v = u + at = at = (Particle initially at rest) or
  • Distance travelled by particle is
  • Kinetic energy gained by particle,



If a charged particle is entering the electric field in perpendicular direction.
Let and the particle enters the field with speed u along x-axis.
Acceleration along Y-axis,
The initial component of velocity along y-axis is zero. Hence the deflection of the particle along y-axis after time t is ;
…… (i)
Distance covered by particle in x-axis,
x = ut …… (ii) ( acceleration ax = 0)
Eliminating t from equation (i) & (ii),
i.e. y ∝ x2.
This shows that the path of charged particle in perpendicular field is parabola.
If the width of the region in which the electric field exists be l then
  1. the particle will leave the field at a distance from its original path in the direction of field, given by
  2. The particle will leave the region in the direction of the tangent drawn to the parabola at the point of escape.
  3. The velocity of the particle at the point of escape is given b

  1. The direction of the particle in which it leaves the field is given by

ELECTRIC DIPOLE

Two equal and opposite charges separated by a finite distance constitute an electric dipole. If –q and +q are charges at distance 2l apart, then dipole moment,
Its SI unit is coulomb metre.
Its direction is from –q to +q. It is a vector quantity.
The torque τ on a dipole in uniform electric field as shown in figure is given by,
So τ is maximum, when dipole is ⊥ to field & minimum (=0) when dipole is parallel or antiparallel to field.
If and
Then



The work done in rotating the dipole from equilibrium through an angle dθ is given by
and from θ1 → θ2,



If θ1 = 0 i.e., equilibrium position, then
Work done in rotating an electric dipole in uniform electric field from θ1 to θ2 is W = pE (cosθ1 – cosθ2 )



Potential energy of an electric dipole in an electric field is,
i.e. U = –pE cosθ
where θ is the angle betweenand .
We can also write

ELECTRIC FIELD DUE TO AN ELECTRIC DIPOLE

  • Along the axial line (or end-on position)
and are parallel
when x >> l
  • Along equatorial line (or broadside on position)
when x >>l
When and are anti parallel then,
Eax = 2 Eeq
  • At any point (from the dipole)
;
Electric field intensity due to a point charge varies inversely as cube of the distance and in case of quadrupole it varies inversely as the fourth power of distance from the quadrupole.

ELECTRIC FORCE BETWEEN TWO DIPOLES

The electrostatic force between two dipoles of dipole moments p1 and p2 lying at a separation r is
when dipoles are placed coaxially
when dipoles are placed perpendicular to each other.



KEEP IN MEMORY
  1. The dipole moment of a dipole has a direction from the negative charge to the positive charge.
  2. If the separation between the charges of the dipole is increased (or decreased) K-times, the dipole moment increases (or decreases) by K-times.
  3. The torque experienced by a dipole placed in a uniform electric field has value always lying between zero and pE, where p is the dipole moment and E, the uniform electric field. It varies directly with the separation between the charges of the dipole.
  4. The work done in rotating a dipole in a uniform electric field varies from zero (minimum) to 2pE (maximum). Also, it varies directly with the separation between the charges of the dipole.
  5. The potential energy of the dipole in a uniform electric field always lies between +pE and –pE.
  6. The electric field intensity at a point due to an electric dipole varies inversely with the cube of the distance of the point from its centre if the distance is much greater than the length of the dipole.
  7. The electric field at a point due to a small dipole in end-on position is double of its value in broad side-on position,
i.e. EEnd-on = 2EBroad side-on
  1. For a small dipole, the electric field tends from infinity at a point very close to the axis of the dipole to zero at a point at infinity.
  2. The force between two dipoles increases (or decreases) by K4-times as the distance between them decreases (or increases) by K-times.
  3. Time period of a dipole in uniform electric field is
where I = moment of inertia of the dipole about the axis of rotation.

ELECTRIC FLUX

Electric flux is a measure of the number of electric field lines passing through the surface. If surface is not open & encloses some net charge, then net number of lines that go through the surface is proportional to net charge within the surface.
For uniform electric field when the angle between area vector and electric field has the same value throughout the area,
For uniform electric field when the angle between the area vector and electric field is not constant throughout the area



KEEP IN MEMORY
  1. The electric flux is a scalar although it is a product of two vectors and (because it is a scalar product of the two).
  2. The electric flux has values lying between –EA and +EA, where E and A are the electric field and the area of cross-section of the surface.

GAUSS’S LAW

It states that, the net electric flux through a closed surface in vacuum is equal to 1/εo times the net charge enclosed within the surface.
i.e.,
where Qin represents the net charge inside the gaussian surface S.
Closed surface of irregular shape which enclosed total charge Qin



In principle, Gauss’s law can always be used to calculate the electric field of a system of charges or a continuous distribution of charge. But in practice it is useful only in a limited number of situation, where there is a high degree of symmetry such as spherical, cylindrical etc.
  • The net electric flux through any closed surface depends only on the charge inside that surface. In the figures, the net flux through S is q1o, the net flux through S’ is (q2 +q3 )/εo and the net flux, through S” is zero.

A point charge Q is located outside a closed surface S. In this case note that the number of lines entering the surface equals to the number of lines leaving the surface. In other words the net flux through a closed surface is zero, if there is no charge inside.
  • The net flux across surface A is zero
i.e.,
because Qin = – q + q = 0

APPLICATIONS OF GAUSS’S LAW

  • To determine electric field due to a point charge
The point charge Q is at the centre of spherical surface shown in figure.
Gaussian surface and is parallel to (direction normal to Gaussian surface) at every point on the Gaussian surface.
so,

  • To determine electric field due to a cylindrically symmetric charge distribution
We calculate the electric field at a distance r from a uniform positive line charge of infinite length whose charge per unit length is λ = constant. The flux through the plane surfaces of the Gaussian cylinder is zero, since is parallel to the plane of end surface (is perpendicular to ). The total charge inside the Gaussian surface is λl, where λ is linear charge density and l is the length of cylinder.
Now applying Gauss’s law and noting is parallel to everywhere on cylindrical surface, we find that



KEEP IN MEMORY
  1. The closed imaginary surfaces drawn around a charge are called Gaussian surfaces.
  2. If the flux emerging out of a Gaussian surface is zero then it is not necessary that the intensity of electric field is zero.
  3. In the Gauss’s law,
 is the resultant electric field due to all charges lying inside or outside the Gaussian surface, but Qin is the charge lying only inside the surface.



  1. The net flux of the electric field through a closed surface due to all the charges lying inside or outside the surface is equal to the flux due to the charges only enclosed by the surface.
  2. The electric flux through any closed surface does not depend on the dimensions of the surface but it depends only on the net charge enclosed by the surface.

Leave a Reply

Your email address will not be published. Required fields are marked *
